body { font-size: 75%; color: #000; font-family: Open Sans,Arial,Helvetica,sans-senif,SimSun,"宋体"; line-height: 1.3; } dl { margin: 0px; width: 480px; float: left; } dt { width: 100px; height: 15px; float: left; } dd { width: 240px; height: 15px; float: left; } dl dt { margin: 0px; line-height: 22px; color: #474747; font-size: 14px; font-family: tahoma; } #product-desc { width: 100%; height: 209px; } #description { width: 100%; height: 50%; } #details { width: 100%; height: 50%; } .ui-box-title { height: 30px; font-size: 15px; font-family: tahoma; font-weight: bold; background-color: #ddd; text-anchor: inherit; padding-top: 8px; margin: 0px; } .ui-box-body { margin: 0px; } #tbspecifics { border-right: 1px solid black; border-bottom: 1px solid black; } #tbspecifics tr { height: 30px; } #tbspecifics td { width: 100px; border-left: 1px solid black; border-top: 1px solid black; } Step 1: Remove the air cleaner and duct hose assembly using the common screwdriver. Disconnect the electrical connector on the mass air flow by pulling out the plug. Disconnect the intake air temperature sensor found in the air duct.
Step 2: Disconnect the idle air control on the side of the throttle body by pulling the electrical connector out. Disconnect the throttle position sensor opposite the throttle cable levers.
Step 3: Disconnect the throttle cables by turning the throttle lever on the throttle body all the way open by hand and then removing the now slackened cables from the throttle lever.
Step 4: Remove the heated water hoses from the bottom of the throttle body if there are any (this is vehicle dependent). Use the needle nose pliers to remove the clamps by squeezing the clamps and pulling them off. Pull the hoses off. Not all vehicles have these, although there are a few that do.
Step 5: Remove the four bolts running through the throttle body and into the intake manifold. Use appropriate ¼-inch drive socket and ratchet. Lift the throttle body off the intake manifold. Protect the metal gasket that is in between the throttle body and intake. This gasket must be reused. Install the new throttle body and components in reverse order of removal.
100% brand new and high quality
Part number: 04891735AC, 4891735AB, 4891735AA, 4891735
Replacement part number:04891735AC 4884551AA
The electronic throttle unit opens and closes the throttle blade based on input from various engine control sensors, including the accelerator pedal
Fit For:
For 2007-2016 JEEP PATRIOT WITH 1.8L 2.0L 2.4L
For2007-2016 JEEP COMPASS WITH 1.8L 2.0L 2.4L
For2007-2012 DODGE CALIBER WITH 1.8L 2.0L 2.4L
For2008-2014 DODGE AVENGER WITH 1.8L 2.0L 2.4L
For2009-2016 DODGE JOURNEY WITH 1.8L 2.0L 2.4L
For2011-2016 CHRYSLER 200 WITH 1.8L 2.0L 2.4L
Colour:Silver
Material:aluminum
Package Contents:
1 * Throttle Body
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
