Description


This machine is a new material testing machine combining electronic technology with software technology and mechanical transmission. It adopts stepper motor as precision power source. It adopts imported precision ball drive screw and guide rod, adopting imported grade 0.5. The precision force value sensor is then accurately measured by a high-precision force value measurement system. This series of models adopts single space structure, which is mainly used for material testing with load less than 10kN. It has firm structure, convenient operation and simple maintenance. It is an ideal test instrument for mechanical testing in various factories and enterprises. It has a wide and accurate loading speed and force range. It has high precision and sensitivity for measurement and control of load, deformation and displacement. It has stress, strain and displacement modes, and can find the maximum force value, tensile strength and bending strength, compression strength, modulus of elasticity, elongation at break, yield strength and other parameters, suitable for tensile, compression, peeling, tearing, shearing, etc. mechanical properties test and analysis.

Application Industry

Rubber and plastics; metrological quality inspection; commodity inspection and arbitration; technical supervision department; colleges and universities; scientific research laboratory; basic materials laboratory; metallurgical steel; machinery manufacturing; electronic appliances; automobile production; textile chemical fiber; wire and cable; packaging materials and food; Instrumentation; medical equipment; petrochemical; civil nuclear energy; aerospace; ceramic materials; magnetic materials industry; energy batteries; basic materials;

Standard

ASTM, ISO, DIN, GB and other international standards.

Application Products

》Plastic

》Film

》Fiber and thin wire

》Adhesive

》Foam material
》Tape

》Elastomer

》Connector

》Biomaterials

》Wood and paper products

》Metal foil

》Metallic line

》Below medium strength metal

》Oil bearing
》Ceramic

》Part

》Fastener

》Composite material

Main Feature

u Meet most of the mechanical properties test

u Completely compact structure, high rigidity design, durable

u Easy to operate, anyone can operate

u High accuracy, certified by a third-party testing agency

u High speed, low vibration, low noise motor drive

u Multilingual application function, adapt to different countries’ using

u Capabilities with graph, data sheet, report viewing and printing

u Automatic returning function after test completed

u Automatic calculation of maximum force, minimum force, average force, maximum deformation, elongation, strength, etc.

u Has a variety of curve modes such as stress-strain, force-displacement, force-time, intensity-time

u Has test mode functions such as tensile, flexural, compressive, flexural, adhesive, tear, peel, elongation, etc.

u With mechanical travel switch; emergency stop switch; over current, over voltage, under current, under voltage, leakage overload protection; software overload limit protection; breakpoint shutdown protection and other multiple protection devices

u Optional: small deformation metal extensometer, large deformation displacement tracker

Technical Instruction

Brand

HongTuo

Model

WDW-S

-005

-01

-02

-05

-1

-2

-5

-10

Capacity

KN

0.05kN

0.1 kN

0.2 kN

0.5kN

1 kN

2kN

5kN

10KN

KG

5kg

10kg

20kg

50kg

100kg

200kg

500kg

1000kg

lb

Structure

Double rail structure

Three double rail structure

Unit switching

G、Kg、lb、N、KN

Displacement unit switching

Inch  cm   mm

Test machine level

1class

Effective force range

0.4％～100％FS

Force accuracy

Within ±0.5%

Force decomposition

1/200 000

Force Power magnification

X1,X2,X5,X10,X20,X50,X100.,etc.Seven-speed automatic shifting

Displacement resolution

0.05mm

Displacement accuracy

Within ±1%

Deformation measurement range

2%～100%FS

Deformation indication accuracy

Within ±1%

Large deformation measurement range

(0～800)mm

Large deformation resolution

0.05mm

Large deformation indication error limit

Within ±1%

Maximum test speed

500mm/min；optional maximum 1000mm/min

Minimum test speed

0.1mm/min

Speed accuracy

Within ±1%

Beam travel

Measuring height

standard

No grip testing stroke：920mm；With grip testing stroke：320mm

optional

No grip testing stroke：1320mm；With grip testing stroke：320mm

Fixture configuration

One set of tensile grip；can choose other grips

Returning method

Manual or automatic selection, automatically return after the test ends or manually return to the initial position

Stop method

1.Maximum break value automatically stop     2.Upper and lower limit safety setting stop

Safety devices

1.Mechanical limit switch protection     2.Emergency stop switch emergency brake

Overload  protection

Over 10% of maximum load, automatic machine protection

Accessories

1 power cord; 1 test software program CD; 1 data cable; 1 manual; 1 certificate

Optional accessories

 Anti-splash device (protective door); printer

Powder supply

220V.AC/ 50HZ; 110V.AC/60HZ

Main host size/ weight

Standard model:Length*Width*Height:450mm*400mm*1160mm / Around 50KG

Heightening model:Length*Width*Height:450mm*400mm*1550mm / Around 55KG

Packing size / weight

Standard model:Length*Width*Height:550mm*500mm*1400mm / Around 73KG

Heightening model:Length*Width*Height:550mm*500mm*1800mm / Around 78KG
