Technical data sheet


product name

5-port AF PoE switch with 4 PoE ports and 1 uplink

model

ZX901-AF-41

Connector type

5x 10 / 100M copper RJ45 port (4 PoE ports + 1 uplink)

Internet media

10BASE-T: Cat6 UTP (≤250m); 100BASE-TX: Cat5 or higher UTP (≤100m);

1000BASE-TX: Cat5 or higher UTP (≤100 meters)

bandwidth

1.0Gbps (non-blocking)

Address database size

1K

MTBF

190,000 hours (about 21 years)

Forwarding mode

Storage and forwarding

Network protocol

IEEE 802.3i 10BASET; IEEE 802.3u 100BASETX; IEEE 802.3x flow control;

IEEE 802.1af DTE power supply via MDI; IEEE 802.3af

LED display

System: Power; each port: connection, PoE working status

power supply

Power input: AC100-240V 50 / 60Hz; (customized power plugs are used in every country)

PoE port

Port1-4 supports POE

PoE port power supply

15.4W per POE port

PoE standard

IEEE 802.3af

PoE function

MDI / MDIX is supported on all ports

working environment

Working temperature: -20 ° ~ 55 ° C; storage temperature: -40 ° ~ 85 ° C;

Working humidity: 10%~95%, no condensation

prove

CE Mark, commercial; CE / LVD EN60950, RoHS

radiation

CE mark, commercial; FCC Part 15 Class B; VCCI Class B; EN 55022 (CISPR 22),

Class B

Transmission distance

Data transmission distance: 100 meters

net weight

0.16 kg

total weight

0.46 kg

Product Size

11 cm* 6.9 cm* 2.6 cm

Package dimensions

20.8 cm * 17 cm * 4.7 cm
