Features:
1. All components are original products to ensure the reliability of the ESC.
2. Compatible with various remote controllers and receivers.
3. With smooth and delicate speed control feel and good linearity

use:
Mini car, mini model airplane, mini drone, mini multi-rotor ESC, 360 degree continuous rotation servo, remote control car winch control circuit, etc.
Used for 360-degree continuous rotation steering gear, digital circuit, no need for potentiometer adjustment, save worry and effort

Specification:
Model No.: DM-ESC001
Weight: 0.4g
Size: 12x8.5mm
Voltage: 3.5-6v
Continuous current: 1A, maximum current 1.5A
PWM range: 1000~2000US
Wire length: 200mm
Motor cable length: 20mm
Single board weight: about 0.4g (excluding wire)
BEC output: None
Direction of rotation: bidirectional, positive and negative,
Applicable motor: brush motor
Compatible with Futaba, JR, SANWA, Hitec and other well-known remote control systems.

The 360-degree servo is PWM to control its rotation speed and direction. The 1000-1500us PWM controls its forward rotation. The smaller the value, the greater the rotation speed; the 1500-2000us PWM is its reverse rotation, and the larger the value, it rotates. The greater the speed. 1500us PWM is to control it to stop. Can only rotate continuously, not positioning.

Digital circuit, no need for potentiometer to adjust the stop position, save worry and effort

hint:
1. The standard connector (JR) is produced by default, because JR connector is compatible with other connectors;
2. Before installation and use, you must read the instructions carefully to avoid unnecessary damage;
3. Please select the appropriate specifications, do not overload the specifications, otherwise the mechanism or parts will be damaged;
4. Refer to the specifications to select the correct power supply voltage, and ensure that sufficient current is supplied, so as not to affect the normal operation of the steering gear; use beyond the voltage range may cause abnormal operation or even damage, which requires special attention;
5. Keep the working environment clean and avoid the erosion and pollution of dust, corrosive gas or humid air;
6. Reserve the right to modify product specifications without notice;

Package:
PE bag, 1pcs/bag, or bulk
