Mini ESP8285 ESP-M3 WiFi Module Wireless Transmission with Pins for Arduino Smart Device Development Board Replace ESP8266

What is ESP8285?
ESP8285 = ESP8266 + 1M Flash, so that it can withstand high temperatures up to 125 degrees Celsius! And the original ESP8266 source code program can be used to transplant.
ESP-M3 module core processor using cost-effective chip ESP8285. The chip integrates the enhanced version of the Tensilica's L106 Diamond 32-bit core processor with on-chip SRAM in a smaller package. ESP8285 has a complete Wi-Fi network function, both can be used independently, can also be used as a slave from other host MCU running. When the ESP8285 hosting application, can be started directly from the external Flash. Built-in cache memory facilitates system performance and optimizes storage systems. In addition, ESP8285 only through the SPI / SDIO interface or I2C / UART port can be used as a Wi-Fi adapter, applied to any microcontroller-based design.

Features
1) the volume is ultra-small;
2) serial to WiFi;
3) wireless transmission;
4) long-range ultra-low power consumption;
5) high temperature, up to 125 ℃
6) fully compatible with ESP8266, the source can be used to transplant.

SOC characteristics
Built-in Tensilica L106 ultra-low power 32-bit microprocessor, clocked at 80MHz and 160MHz support RTOS
Built-in TCP / IP protocol stack
Built-in 1-channel 10-bit high-precision ADC
Peripheral Interface HSPI, UART, I2C, I2S, IR Remote Control, PWM, GPIO
The deep sleep hold current is 10uA and the shutdown current is less than 5uA
Wake up within 2 ms, connect and pass the packet
Standby power consumption less than 1.0mW (DTIM3)
Built-in 1M bytes of SPI Flash

Wi-Fi features
Supports 802.11 b / g / n / e / i
Support Station, SoftAP, SoftAP + STA mode
Support for Wi-Fi Direct (P2P)
Supports CCMP (CBC-MAC, counter mode), TKIP (MIC, RC4), WAPI (SMS4), WEP (RC4), CRC hardware acceleration
P2P discovery, P2P GO mode / GC mode and P2P power management
WPA / PA2 PSK and WPS
802.11 i security features: pre-authentication and TSN
Hold 802.11n (2.4 GHz)
802.1h / RFC1042 frame encapsulation
Seamless roaming support
Support AT remote upgrade and cloud OTA upgrade
Support for Smart Config features (including Android and iOS devices)

Module peripherals
2xUART
1xADC
1xEn
1x wakeup pin
1xHSPI
1xI2C
1xI2S
Up to 10xGPIOs
Operating temperature range: -40 ℃ -125 ℃

Application scenario
Household appliances
Home automation
Smart socket, smart light
Mesh network
Baby monitor
IP camera
sensor network
can wear electronic products
Security ID tag
Wireless location awareness
Wireless positioning system beacon
Industrial wireless control

Package include:
1 * Mini ESP8285 ESP-M3 WiFi Module
